| Place of Origin: | Guangdong , China (Mainland) |
|---|---|
| Brand Name: | DDW |
| Certification: | ISO9001 , CE , RoHS , FCC |
| Model Number: | DDW-LW550HN16 |
| Minimum Order Quantity: | 2pcs |
| Price: | Negotiable |
| Packaging Details: | First layer carton pack with filling foam , then wood pallet pack |
| Delivery Time: | 3 working days upon payment |
| Payment Terms: | T/T , Western , L/C Union , Alibaba trade assurance |
| Supply Ability: | 3 , 000pcs per month |
| Type: | Vertical | Brightness: | 500 Nits |
|---|---|---|---|
| Application: | Exhibition And Show Center | Refresh Rate: | 60Hz |
| Response Time: | <=6ms | Dot Pitch: | 0.63x0.63 Mm |
| Active Area: | 1209.6 × 680.4 Mm | ||
| High Light: | ultra narrow bezel video wall,multi screen video wall |
||
Vertical 3*3 LCD Video Wall Display For Exhibition And Show Center
LCD Video Wall Display Application
LCD Video Wall Display main parameters
1. Only 1.7 mm ultra narrow bezel, high quality ,practical ,good vision effect.
2. 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output
3. HD video wall unit--- High brightness,high contrast,high gamut .
4. Flexible structure design ---easy installation ,extensible,arbitrary combination
5. Stable performance,suitable working for a long time
LCD Video Wall Display Specifications
| Model No: | DDW-LW550HN16 LCD Video Wall Display |
| Active Screen Diagonal | 55" |
| Pixel Pitch(WxH) | 0.63x0.63 mm |
| Active Display Area(WxH) | 1209.6 × 680.4 mm |
| Panel Dimension(WxHxD) | 1211.54 x 682.34x68.1mm |
| Total Bezel Width | 1.7 mm |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920x1080 |
| Backlight System | LED |
| Luminance(nits) | 500cd/sqm |
| Surface | Anti-glare |
| Standby Power Consumption | <3W |
| Maximum Power Consumption | <=250W |
| Power Supply | AC100~240V 50/60 HZ |
| Cooling | Low noise fans |
| Heat Dissipation | 819 BTU/h (max) |
| Working Time Capacity | 7x24x365hours |
| Application Area | Indoor/Semi Outdoor/Outdoor |
| Working Temperature | 0°C~50°C |
| Working Humidity | 85% non-condensing |
| Storage Temperature | -20-60°C | -4-149°F |
| Storage Humidity | 85% non-condensing |
LCD Video Wall Display Board Specification
| Support | PC | color | 24bit |
| signal | Line synchronization range | 30-80KHZ | |
| Field synchronization range | 50-75HZ | ||
| DVI | color | 24bit | |
| HDMI | Line synchronization range | 30-80KHZ | |
| DP | Field synchronization range | 50-75HZ | |
| Interface | input | VGA x 1 | 15pin D-Sub |
| DVI x 1 | DVI-I | ||
| DP x 1 | Display Port | ||
| HDMI x 2 | HDMI-19 pin | ||
| output | PANEL | LVDS 36Pin/2.0 | |
| DP out | DP loop out | ||
| Power | Input power | DC24V/12V/5V | |
| Drive panel | 5V/12V | ||
| Power mode | Normal working mode, power saving mode | ||
| Other | OSD | Chinese, English and other languages (other languages can be added as required) | |
LCD Video Wall Display Details
