IP65 IP54 Fixed Full Color LED Display Easy Installation Energy Saving Noiseless

Basic Information
Place of Origin: Guangdong , China (Mainland)
Brand Name: DDW
Certification: ISO9001 , CE , RoHS , FCC
Model Number: DDW-LEDP5
Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: First layer carton pack with filling foam , then wood pallet pack
Delivery Time: 3 working days upon payment
Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
Supply Ability: 3 , 000pcs per month
Detail Information
Product Name: LED Video Wall Display Feature: Energy Saving
Input AC Power Voltage: AC90~264V Working Humidity: 10%-95%RH
Refresh Rate: ≥1920 Hz Viewing Angle: 140/120 Hor/Vert°
Gray Scale: 65536 Drive Mode: Constant Driving,1/8S
High Light:

seamless led video wall

,

large display wall


Product Description

AC90~264V Fixed LED Video Wall Display Easy Installation Energy Saving Noiseless





LED Video Wall Display Main Features



IP65 front Water proof

High protection grade of IP65 guarantees,Durability, Reliability, Anti-ultraviolet and Steady.



Dual channel heat dissipation

Low power consumption and fast heat dissipation/ energy saving and environment protection.



Super wide angle

Wide Viewing Angle can achieve to Vertical viewing 150 Horizontal viewing 120.



LED Video Wall Display​ Specification

Pixel Configuration SMD2727
Pixel Pitch(mm) 5
Pixel Density(dot/m2) 40000
Module Pixel Matrix (W×H) 64×32
Module Size(mm) 320(W)×160(H)
Module Weight(kg) 0.8
Module Power Consumption Max.(W) 20
Module/Panel(W×H) 3×6
Panel Resolution(W×H) 192×192
Panel Size(mm) 960(W)×960(H)
Panel Weight(kg) 35
Maitainence Mode Rear Maitainence
Panel type Steel cabinet
Brightness(nits) ≥5000
Color Temperature(K) 3200—9300
Viewing Angle(Hor/Vert°) 140/120
Power Consumption Max(W/m2) 1000
Power Consumption Avg(W/m2) 200-300
Operating Power Source AC90~264V,Frequency 47-63(Hz)
Frame Frequency(Hz) 50&60
Drice Mode Constant Driving,1/8 Scan
Gray Scale 65536
Refresh Rate(Hz) ≥1920
Gray Scale per Color Level 16bit
Working Temperature/Humidity(℃/RH) -20 – 60 / 10%-85%RH
Storage Temperature/Humidity(℃/RH) -20 – 60 / 10%-85%RH
