| Place of Origin: | Guangdong , China (Mainland) |
|---|---|
| Brand Name: | DDW |
| Certification: | ISO9001 , CE , RoHS , FCC |
| Model Number: | DDW-LW550DUN-THA3 |
| Minimum Order Quantity: | 2pcs |
| Price: | Negotiable |
| Packaging Details: | First layer carton pack with filling foam , then wood pallet pack |
| Delivery Time: | 3 working days upon payment |
| Payment Terms: | T/T , Western , L/C Union , Alibaba trade assurance |
| Supply Ability: | 3 , 000pcs per month |
| Product Name: | LG Super Narrow Bezel Control Room Video Wall | Resolution: | 3840 X 2160 |
|---|---|---|---|
| Bezel Width: | 1.8mm | Viewing Angle: | 178 X 178 |
| Brightness: | 700nits | Surface: | Anti-glare |
| Backlight: | WLED | Control Method: | RS232 Control |
| Response Time: | 5ms | Input Voltage: | AC 110-240v |
| Signal Support: | DVI//VGA/AV/YPBPR | Working Time Capacity: | 7x24hours |
| High Light: | control room displays,hd video wall |
||
Super narrow beze monitorl 4K control room video wall 55" LG lcd display DDW-LW550DUN-THA3
DDW offers a range of scalable connectivity and display processing systems for corporate av applications, as well as large-scale multiscreen video wall solutions for enterprise-level installations. The remote capabilities and real-time signal processing provided by our conference, board, collaboration and control room display systems support multi-site workflows and critical decision-making.
Key features
1, Signal interface rich --- RS232, , DVI, VGA,YPbPr, AV;
2, HD video wall unit--- High brightness, high contrast, high gamut;
3, Flexible structure design ---easy installation, extensible, arbitrary combination;
4, Stable performance, suitable working for a long time;
5, Original Innolux commercial grade lcd video wall panel,16:9 a-Si TFT-LCD;
6, 700nits brightness, 4000:1 contrast;
7, HD physical resolution 3840 x 2160;
8, only 1.8mm ultra narrow bezel, high quality, practical, good vision effect;
Service
Our customizable solutions offer a range of user-friendly features that streamline operation and enable the interconnectivity of your corporate control room, meeting rooms, and multi-screen display systems. Integrating a range of content types and signal formats, DDW’s multi screen video wall, control room display and digital signage systems can help you get your message across to customers more effectively.
Specifications
| Panel Specifications | ||||||||||
| Active Screen Diagonal | 55" | |||||||||
| Total Bezel Width | 1.8mm | |||||||||
| Aspect Ratio | 16:9 | |||||||||
| Physical Resolution | 3840x2160 | |||||||||
| Backight System | LED | |||||||||
| Luminance(nits) | 700cd/㎡ | |||||||||
| Contrast | 4000:1 | |||||||||
| Viewing Angle | H 178°|V 178° | |||||||||
| Pixel Pitch(WxH) | 0.63x0.63 mm | |||||||||
| Active Display Area(WxH) | 1209.6×680.4mm | |||||||||
| Panel Dimension(WxHxD) | 1211.4x682.2x53.3mm | |||||||||
| White Point | 10,000 K | |||||||||
| Display Colors | 1.07GB colors | |||||||||
| Refresh Rate | 60Hz | |||||||||
| Response Time | <=6ms | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| MTBF | > 100,000 h | |||||||||
| Surface | Anti-glare | |||||||||
| Standby Power Consumption | <3W | |||||||||
| Maximum Power Consumption | ≦160W | |||||||||
| Power Supply | AC100~240V 50/60 HZ | |||||||||
| Cooling | Low noise fans | |||||||||
| Heat Dissipation | 819 BTU/h (max) | |||||||||
| Working Time Capacity | 7x24x365hours | |||||||||
| Application Area | Indoor/Semi Outdoor | |||||||||
| Working Temperature | 0℃～50℃ | |||||||||
| Working Humidity | 0.85 | |||||||||
| Storage Temperature | -20-60°C | -4-140°F | |||||||||
| Storage Humidity | 85% non-condensing | |||||||||
| Inputs, Outputs &Features | ||||||||||
| DVI-I DUAL LINK | 1 | |||||||||
| 1 | ||||||||||
| VGA | 1 | |||||||||
| CVBS IN | 1 | |||||||||
| CVBS OUT | 1 | |||||||||
| RS232 IN | 1 | |||||||||
| RS232 OUT | 1 | |||||||||
| ISP IN | 1 | |||||||||
| IR IN | 1 | |||||||||
| AC IN | AC100-240V | |||||||||
| Color System Support | PAL/NTSC/SECAM | |||||||||
| Control Type | IR Remote &Software Control | |||||||||
| Menu Language | English/Chinese(Multiple Language can be customized) | |||||||||
| Vertical/Horizontal Display | Support | |||||||||
| Combine Display | Support combine any horizental &vertical numbers of screens and show display | |||||||||
| Support combine all screens together to show 1image | ||||||||||
| Solid Display | Support each screen input with separate signal | |||||||||
| PIP/Zoom/Roaming | Support open one window for each screen, each window can be zoomed &roaming internal freely | |||||||||
| Multiple Interfaces | Support DVI,,VGA,AV &multiple signal inputs | |||||||||
| Rich Resolution | Support 1080P,1080I,720P,480P &multiple resolution inputs | |||||||||
