Super thin bezel LG 3x3 video wall tv screens panel resolution 1920x1080

China Super thin bezel LG 3x3 video wall tv screens panel resolution 1920x1080 supplier
Super thin bezel LG 3x3 video wall tv screens panel resolution 1920x1080 supplier Super thin bezel LG 3x3 video wall tv screens panel resolution 1920x1080 supplier Super thin bezel LG 3x3 video wall tv screens panel resolution 1920x1080 supplier Super thin bezel LG 3x3 video wall tv screens panel resolution 1920x1080 supplier

Large Image :  Super thin bezel LG 3x3 video wall tv screens panel resolution 1920x1080

Product Details:

Place of Origin: Guangdong , China (Mainland)
Brand Name: DDW
Certification: ISO9001 , CE , RoHS , FCC
Model Number: LW460HN14

Payment & Shipping Terms:

Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: First layer carton pack with filling foam , then wood pallet pack
Delivery Time: 3 working days upon payment
Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
Supply Ability: 3 , 000pcs per month
Contact Now
Detailed Product Description
Panel Size: 46 Inch Resolution: 1920x1080
Bezel Width: 1.7mm Color: 8Bit , 16M
Brightness: 500 Nits Surface: Anti-glare
Backlight: LED Control Method: RS232 Control
Signal Support: DVI/HDMI/VGA/AV/YPBPR Working Time Capacity: 7x24hours
Pixel Pitch: 0.5302x0.5302mm Application Condition: Indoor And Semi-outdoor

Super thin bezel LG 3x3 video wall tv screens panel resolution 1920x1080





Advertising video wall technology is a high quality image representative of serial transmission, mainly used in some professional field of television and radio and television, the product supports audio embedded solution, at the same time, supports the highest resolution to 1080p 60Hz, which should be more extensive.



46" LG advertising video wall main parameters

  1. Original LG commercial grade lcd video wall display panel, 16:9 LG a-Si TFT-LCD;
  2. 500nits brightness, MEGA DCR contrast;
  3. FHD physical resolution 1920x1080;
  4. Only 1.7mm Ultra narrow bezel, high quality, practical, good vision effect;
  5. Signal interface rich --- RS232, HDMI, DVI, VGA, YPbPr, AV;
  6. HD video wall unit--- High brightness, high contrast, high gamut;
  7. Flexible structure design ---easy installation, extensible, arbitrary combination;
  8. Stable performance, suitable working for a long time;

Key features:

  • Support a variety of signal ports.
  • Built-in splicing module, Support splice function
  • Support Creating one window PIP across the screen, roaming service, scaling,PIP
  • Support matrix joint control.
  • Unique DNX motion supplement image processing technology,
  • Dynamic image without motion trail
  • Splicing image processing RS-232 RJ45 loop-circuit input/output.
  • Input by remote control with wire, mobile receiver head.

Specifications:

Model No: LW460HN14
LCD Technology LG IPS LCD
Active Screen Diagonal 46"
Total Bezel Width 1.7mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backight System WLED
Luminance(nits) 500cd/sqm
Contrast MEGA DCR
Viewing Angle H 178°|V 178°
Pixel Pitch(WxH) 0.5302x0.5302mm
Active Display Area(WxH) 1018.08×572.67mm
Panel Dimension(WxHxD) 1020.02x574.61x68mm
White Point 10,000 K
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000 h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption lower than 250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor
Working Temperature 0°C~50°C
Working Humidity 0.85
Storage Temperature -20-60°C | -4-140°F
Storage Humidity 85% non-condensing
HDMI 1
VGA 1
CVBS IN 1
CVBS OUT 1
RS232 IN 1
RS232 OUT 1
ISP IN 1
IR IN 1
CODING BUTTON 1
AC IN AC100-240V
Color System Support PAL/NTSC/SECAM
Control Type IR Remote &Software Control
Menu Language English/Chinese(Multiple Language can be customized)
Vertical/Horizontal Display Support
Combine Display Support combine any horizontal &vertical numbers of screens and show display
Support combine all screens together to show 1image
Solid Display Support each screen input with separate signal
PIP/Zoom/Roaming Support open one window for each screen, each window can be zoomed &roaming internal freely
Multiple Interfaces Support DVI,HDMI,VGA,AV &multiple signal inputs
Rich Resolution Support 1080P,1080I,720P,480P &multiple resolution inputs

Super thin bezel LG 3x3 video wall tv screens panel resolution 1920x1080

Super thin bezel LG 3x3 video wall tv screens panel resolution 1920x1080

Applications:

Advertising video wall can be used in below fields: Conference and meeting rooms, office building, lobbies, security monitoring center, surveillance and retail center, restaurant and hotel, retail shopping mall advertising and information displays, public installations, exhibition and show center, live show, rental and advertising center,museums,church,transportation and mass info display systems.
