Resolution 1920x1080 Outdoor Digital Display Signs 55'' Floor Standing Outdoor Totem

Basic Information
Place of Origin: China
Brand Name: DDW
Certification: CE/CCC/FCC/ROHS/ISO9001
Model Number: DDW-AD5501SPC
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Carton and Full wood box packing
Delivery Time: 20 working days upon payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 set per month
Detail Information
Maximum Resolution: 1920x1080 Average Brightness: 1500-2500cd/mxm
Maximum Power Consumption: 3600W Standby Power Consumption: <5W
Working Temperature: 0- 40 ℃ Storage Temperature: -10℃ — 50℃
Installation: Flood-standing Display Color: 1.073G(10bits/color)
Life(hrs): >60,000(hrs)
High Light:

freestanding digital signage

,

digital display signs outdoor


Product Description

55 inch digital signage display outdoor floor standing digital signage outdoor totem

55” digital signage Key Features
1, 55 inch LCD Module ,1920x1080 resolution , 4000/1 contrast with LED backlight, Sunlight viewable
2, Patented LED backlight modular components + constant current source drive components
3, Patented cooling structure combination of high-quality fan assembly
4, Quad cores CPU 8Gb memory , Latest Android OS network version support LAN control , WIFI control , USB , CF , SD slots , support VGA input , 3G(optional)
5, Automatic ambient light adjustment control (extended life and energy efficiency)
6, Built-in power adapter combination AC220V/DC
7, IP65 grade all waterproof and dustproof metal enclosure +6mm optical protective glass + air cooling/heating system
8, Highly fortified AR glass , protect the LCD screen from direct injury , played the role of anti-riot
9, Rackmount LCD display module + built-in anti-theft locks , patented a unique , easy to disassemble and maintain the site , a unique patent
10, A/C automatic fans Cooling/Heating system , thickness 14cm , Intelligent condition monitoring , real-time detection equipment vibration , temperature and humidity parameters such as power supply , timely warning , Working temperature -10℃ - 50℃
11, Frame(fit with single side screen) can be customized exactly same as client provided
Parameters

LCD parametersModel No.DDW-AD5501WPC
display55" LED
Contrast Ratio16/9
Maximum resolution1920x1080
Display color1.073G(10bits/color)
Life(hrs)>60,000(hrs)
average brightness2500cd/mxm
contrast4000/1
Viewing angleH178°/V178°
Power supplyAC100~240V 50 /60 HZ
Maximum power consumption3600W
Working temperature0- 40 ℃
Storage temperature-10℃ — 50℃
Installationfloor standing
IP65 waterproof caseUsing 1.5mm galvanized steel
Surface spray powder (anti-corrosion, anti-rust)
Outdoor anticorrosive over 7 years
AR anti-reflective glass 3 + 3mm plastic folder
Display screen glassLight transmittance 97%
Reflectivity is less than 3%
Explosion-proof, waterproof, fireproof
UV protection 99%
Display screenIndustrial-grade LED, Original Samsung screen,brightness 2000cd / m2
High brightness 2500 cd/㎡
Full hd 1920x1080
Industrial power supply
automatically adjust the brightness
Electronic control systemPower supplies , timers , remote control panel , photographic plate , speaker , battery , leakage protection switches , sockets , etc .
Cooling systemIntelligent heating and air-cooling system
meet the environment of -20℃ — 55 ℃
LCD display is not blackening
Patented cooling system ensures that the LCD screen without blackening in direct sunlight
Product assembly and aging testIP65 waterproof test
High and low temperature test
Simulated solar radiation test
Aging test
PackagingWooden packaging, sea/air/express(transportation standards)


Functions
1, Video format MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI
2, Audio format Wave/MP3/WMA/AAC
3, Image format JPEG/BMP/TIFF/PNG/GIF
4, Image resolution 480P/720P
5,Play mode:Power on , single card auto loop play classified files auto loop play multi cards
6,Time year/month/day/week/h/m/s , in the top right corner (open and close optional)
7,Timing open & close:Per day 5 times , 7 days a week,free time
8, Timing play 7 days a week,free set the play program everyday
Applications

Business OrganizationsSupermarket , large-scale shopping malls , exclusive agency , chain shops , large-scale sales , star-rated hotels , restaurants , travel agencies , pharmacy .
Financial OrganizationsBanks , negotiable securities , funds , insurance companies , pawnshops , Non-profit Organizations , Telecommunications , post offices , hospital , schools
Public Placessubway , airports , stations , gas stations , toll stations , bookstores , parks , exhibition halls , stadiums , museums , convention centers , ticket agencies , HR market , lottery centers . Real Estate Property , Apartments , villas , offices , commercial buildings , model rooms , property brokers .
EntertainmentsMovie theaters , fitness halls , country clubs , clubs, massage rooms , bars , cafes , Internet bars , beauty shops , golf course


Resolution 1920x1080 Outdoor Digital Display Signs 55'' Floor Standing Outdoor Totem 0Resolution 1920x1080 Outdoor Digital Display Signs 55'' Floor Standing Outdoor Totem 1Resolution 1920x1080 Outdoor Digital Display Signs 55'' Floor Standing Outdoor Totem 2Resolution 1920x1080 Outdoor Digital Display Signs 55'' Floor Standing Outdoor Totem 3Resolution 1920x1080 Outdoor Digital Display Signs 55'' Floor Standing Outdoor Totem 4
