3500 Nits IP66 3840*2160 Wall Mounted Lcd Signage

Product Details

Place of Origin: Guangdong , China (Mainland)

Brand Name: DDW

Certification: ISO9001 , CE , RoHS , FCC

Model Number: DDW-ADO3202W,DDW-ADO4302W,DDW-ADO4902W,DDW-ADO5502W,DDW-ADO6502W,DDW-ADO7502W,DDW-ADO8602W

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: negotiable

Packaging Details: Carton and Full wood box packing

Delivery Time: 3-7working days upon payment

Payment Terms: Western Union, T/T, L/C, D/P, D/A, Alibaba Trade Assurance

Supply Ability: 1000 set per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                IP66 Wall Mounted Lcd Signage, 3840*2160 Wall Mounted Lcd Signage, 3500 Nits Digital Signage Screen


Luminance:	3500nits	Display Scale:	16:9
Backlight Type:	Direct Led	Display Color:	16.7m
Contrast:	3500:1	Viewing Angle:	178°(H)/178°(V)
Protection Level:	IP66	Power Input:	AC220/110V ± 10%,50/60Hz
Frame Color:	Black/white/gray/red/silver	Networking Method:	RJ45,WIFI,4G(optional)

Luminance:	3500nits
Display Scale:	16:9
Backlight Type:	Direct Led
Display Color:	16.7m
Contrast:	3500:1
Viewing Angle:	178°(H)/178°(V)
Protection Level:	IP66
Power Input:	AC220/110V ± 10%,50/60Hz
Frame Color:	Black/white/gray/red/silver
Networking Method:	RJ45,WIFI,4G(optional)

Product Description

IP66 waterproof outdoor lcd signage screen ultra thin 3500nits digital signage screen

>>Key features:
1. 98mm Ultra-thin thickness design , 40mm ultra-narrow equilateral frame design.
2. IP66 Grade, Waterproof, dust-proof, weather-resistant.
3. Low power consumption, rated power for 55 inches is 300W.
4. 3000-5000nits brightness optional(Default brightness 3000nits).
5. The screen adopts the imported Pilkington 4+1.52+4 laminated AR glass, with 96% ultra high light transmittance and 1.6% ultra low reflection rate.
6. The shell is made of the best 6th series aluminum profiles, which helps dissipate heat.
7. The internal heat dissipation uses superconductivity heat dissipation system, coupled with AC fan to ensure operation of the machine went smooth.
9. The internal of intelligent monitoring board installed the probe to collect the data ( including temperature, humidity, smoke, water immersion, access control, speed control... ) for the centralized management in the cloud platform.
10, The best normal operating temperature: -40 to 65 degrees. When temperature reaches -40℃or 65℃, it will auto power off(The threshold can be self set). Actual glass temperature resistance: -40 ° C to 110 ° C.
11. Customization available: horizontal hanging, vertical hanging, floor standing, suspended ceiling, all kinds of brackets and colors.

>>Specifications:

Outdoor LCD poster
Model NO.		32”	43”	49”	55”	65”	75”	86”
model		DDW-ADO3202W	DDW-ADO4302W	DDW-ADO4902W	DDW-ADO5502W	DDW-ADO6502W	DDW-ADO7502W	DDW-ADO8602W
model		DDW- ADO3202S	DDW- ADO4302S	DDW- ADO4902S	DDW- ADO5502S	DDW- ADO6502S	DDW- ADO7502S	DDW- ADO8602S
Panel parameter	Backlight type	Direct led
	Display dimension	698*392 mm	941*529 mm	1074*604 mm	1210*680 mm	1429*804 mm	1650*928 mm	1895*1065 mm
	Display scale	16:9
	Resolution	1920*1080					3840*2160	3840*2160
	Display color	16.7m
	Brightness	3500nits
	Contrast	3500:1
	Viewing angle	178°(H)/178°(V)
	Response time	50ms
	Life span	50000 hours
Function parameter	Main board	Both android and windows motherboards
	Video format	MPG,MPG-1,MPG-2,MPG-4,AVI,MP4,TS,MKV,WMV etc
	Image formats	GIF,JPEG,PNG,BMP
	Audio output	10w
	Audio formats	MP3,24bit linear PCM7.1
	Other formats	PDF/RSS news/Weather report
	Networking method	RJ45,WIFI,4G(optional)
	Update method	Remote,USB flash
	Display mode	Horizontal/vertical full/split screen
	Program upgrade	Remote & hardware upgrading
	Timing switch on/off	Support any time period
Working environmen	Working temperature	-30℃~+80℃
	Storage temperature	-10℃~60℃
	Working humidity	5%~98%
	Storage humidity	5%~98%
	Noise	<68dB
	Protection level	IP66
	Product size	47277798mm	610102198mm	6841154 98mm	763129398mm	883150898mm	1028175098mm	1115199598mm
	Frame color	Black/white/gray/red/silver
	Power input	AC220/110V ± 10%,50/60Hz
	Rated power	130W	180W	260W	300W	400W	600W	800W
	Weight	35kg	45kg	60kg	65kg	90kg	120kg	160kg
