Product Details
Place of Origin: Guangdong , China (Mainland)
Brand Name: DDW
Certification: ISO9001 , CE , RoHS , FCC , IP65
Model Number: DDW-AD4301SN
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Carton and Full wood box packing
Delivery Time: 3-5working days upon payment
Payment Terms: T/T , Western Union , L/C , Alibaba Trade Assurance
Supply Ability: 300 set per month
Maximum Resolution: |
1920x1080 |
Display Color: |
1.073G(10bits/color) |
Life(hrs): |
>60000(hrs) |
Average Brightness: |
1500-2500cd/mxm |
Maximum Power Consumption: |
3600W |
Standby Power Consumption: |
<5W |
Working Temperature: |
0- 40 ℃ |
Installation: |
Flood-standing Or Customized |
Multi Signal Function: |
Support |
Maximum Resolution: |
1920x1080 |
Display Color: |
1.073G(10bits/color) |
Life(hrs): |
>60000(hrs) |
Average Brightness: |
1500-2500cd/mxm |
Maximum Power Consumption: |
3600W |
Standby Power Consumption: |
<5W |
Working Temperature: |
0- 40 ℃ |
Installation: |
Flood-standing Or Customized |
Multi Signal Function: |
Support |
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
Parameters
| screen | size | 43” |
| Backlight | ELED | |
| display scale | 16:9 | |
| Physical resolution | 1920X1080 | |
| viewing angle | H178º V178º | |
| brightness | 400cd/m2 | |
| contrast ratio | 1200:1 | |
| visible area | 940.36HX529.32V | |
| Display color | 1.07B | |
| response time | 6ms | |
| monitor | OSD menu | Support multiple languages |
| Input interface | HDMI*IN*1 | |
| horn | 2W * 3W * 2 | |
| 3.5mm audio | headphone output | |
| android player | CPU chipset | Rk3288 chip, super quad core cortex-a17 architecture processor, main frequency 1.8GHz |
| Memory | 2GB DDR3 | |
| storage | 16GB flash | |
| operating system | Android 7.1 | |
| WiFi network card | WiFi wireless network card 802.11n | |
| SD card | 1 | |
| Interface | Output HDMI * out * 1, RJ45 * 1, USB * 2 | |
| L / R audio output | 1 RCA X2 | |
| Reset / upgrade button | 1 | |
| Shell appearance structure | Face frame protection | 5mm tempered glass |
| Border Protection | Industrial aluminum profile | |
| Rear shell | Hardware cold rolled steel plate spraying | |
| Installation mode | to ground | |
| packing | Net weight | 38kg |
| Gross weight | 36kg | |
| Package size | 169x19.5x70 mm | |
| Power consumption | input voltage | 100~240v 50/60HZ |
| Standby power / rated power | ≤3W/≤95W | |
| work environment | Operating temperature / humidity | -10℃~55℃; Working humidity: 10% RH ~ 90% RH |
| Storage temperature / humidity | -20℃~60℃; Storage humidity: 10% RH ~ 90% RH |
Applications: restuarant; bookstore; theater, supermarket, retail store, ect;
