Multi Monitor Control Room Video Wall 55 Inch RS232 Control Surface DDW-LW550HN16

Basic Information
Place of Origin: Guangdong , China (Mainland)
Brand Name: DDW
Certification: ISO9001 , CE , RoHS , FCC
Model Number: DDW-LW550HN16
Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: First layer carton pack with filling foam , then wood pallet pack
Delivery Time: 3 working days upon payment
Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
Supply Ability: 3 , 000pcs per month
Detail Information
Panel Size: 55inch Resolution: 1920 X 1080
Bezel Width: 1.7mm Color: 8Bit , 16M
Brightness: 500nits Surface: Anti-glare
Backlight: LED Control Method: RS232 Control
Response Time: 5ms Input Voltage: AC 110-240v
Signal Support: DVI//VGA/AV/YPBPR Working Time Capacity: Working Time Capacity 7x24hours
High Light:

hd video wall

,

control room displays


Product Description

RS232 control Surface anti-glare multi monitor wall control room video wall 3500 : 1 Contrast DDW-LW550HN16



DDW offers a range of scalable connectivity and display processing systems for corporate av applications, as well as large-scale multiscreen video wall solutions for enterprise-level installations. The remote capabilities and real-time signal processing provided by our conference, board, collaboration and control room display systems support multi-site workflows and critical decision-making.



Key features

  • Original Samsung Industrial grade LCD video wall screen, 16:9 Samsung a-Si TFT-LCD;
  • 500nits brightness, 3500:1 contrast;
  • FHD physical resolution 1920x1080;
  • Only 1.7mm Ultra narrow bezel, high quality, practical, good vision effect;
  • Signal interface rich --- RS232, , DVI, VGA, YPbPr, AV;
  • HD video wall unit--- High brightness, high contrast, high gamut;
  • Flexible structure design ---easy installation, extensible, arbitrary combination;
  • Stable performance, suitable working for a long time;



Specifications

LCD Technology LG a-Si TFT-LCD
Active Screen Diagonal 55"
Pixel Pitch(WxH) 0.630x0.630mm
Active Display Area(WxH) 1209.6x680.4mm
Panel Dimension(WxHxD) 1211.54x682.34x68.1mm
Total Bezel Width 1.7mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backlight System WLED
Luminance(nits) 500cd/sqm
Contrast 3500:1 (typ.)
Viewing Angle H 178°|V 178°
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption <=250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor/Outdoor
Working Temperature 0°C~50°C
Working Humidity 85% non-condensing
Storage Temperature -20-60°C | -4-149°F
Storage Humidity 85% non-condensing
DVI-I DUAL LINK 1
1
VGA 1
CVBS IN 1
CVBS OUT 1
RS232 IN 1
RS232 OUT 1
ISP IN 1
IR IN 1
CODING BUTTON 1
AC IN AC100-240V
Color System Support

PAL/NTSC/SECAM

Control Type IR Remote &Software Control
Menu Language English/Chinese(Multiple Language can be customized)
