SHENZHEN DDW TECHNOLOGY CO.,LTD Company Profile
products
Home > products > Control Room Video Wall > 5ms Response Time Surveillance video wall VGA AV YPBPR interface control room videowall DDW-LW550DUN-THA3
5ms Response Time Surveillance video wall VGA AV YPBPR interface control room videowall DDW-LW550DUN-THA3
5ms Response Time Surveillance video wall VGA AV YPBPR interface control room videowall DDW-LW550DUN-THA3
5ms Response Time Surveillance video wall VGA AV YPBPR interface control room videowall DDW-LW550DUN-THA3
5ms Response Time Surveillance video wall VGA AV YPBPR interface control room videowall DDW-LW550DUN-THA3

5ms Response Time Surveillance video wall VGA AV YPBPR interface control room videowall DDW-LW550DUN-THA3

Product Details

Place of Origin: Guangdong , China (Mainland)

Brand Name: DDW

Certification: ISO9001 , CE , RoHS , FCC

Model Number: DDW-LW550DUN-THA3

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: First layer carton pack with filling foam , then wood pallet pack

Delivery Time: 3 working days upon payment

Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance

Supply Ability: 3 , 000pcs per month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

hd video wall

,

samsung commercial displays

Panel Size:
55inch
Resolution:
1920 X 1080
Bezel Width:
1.8mm
Color:
8Bit , 16M
Brightness:
700nits
Surface:
Anti-glare
Backlight:
LED
Control Method:
RS232 Control
Response Time:
5ms
Input Voltage:
AC 110-240v
Signal Support:
DVI//VGA/AV/YPBPR
Working Time Capacity:
Working Time Capacity 7x24hours
Panel Size:
55inch
Resolution:
1920 X 1080
Bezel Width:
1.8mm
Color:
8Bit , 16M
Brightness:
700nits
Surface:
Anti-glare
Backlight:
LED
Control Method:
RS232 Control
Response Time:
5ms
Input Voltage:
AC 110-240v
Signal Support:
DVI//VGA/AV/YPBPR
Working Time Capacity:
Working Time Capacity 7x24hours
Product Description

5ms Response Time Surveillance video wall VGA AV YPBPR interface control room videowall DDW-LW550DUN-THA3



Key features

  • Original Samsung Industrial grade LCD video wall screen, 16:9 Samsung a-Si TFT-LCD;
  • 700nits brightness, 3500:1 contrast;
  • FHD physical resolution 1920x1080;
  • Only 1.8mm Ultra narrow bezel, high quality, practical, good vision effect;
  • Signal interface rich --- RS232, , DVI, VGA, YPbPr, AV;
  • HD video wall unit--- High brightness, high contrast, high gamut;
  • Flexible structure design ---easy installation, extensible, arbitrary combination;
  • Stable performance, suitable working for a long time;

Specifications

Active Screen Diagonal 55"
Pixel Pitch(WxH) 0.630x0.630mm
Active Display Area(WxH) 1209.6x680.4mm
Panel Dimension(WxHxD) 1211.4x682.2x53.3mm
Total Bezel Width 1.8mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backlight System LED
Luminance(nits) 700cd/sqm
Contrast 5000:1 (typ.)
Viewing Angle H 178°|V 178°
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption <=250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor/Outdoor
Working Temperature 0°C~50°C
Working Humidity 85% non-condensing
Storage Temperature -20-60°C | -4-149°F
Storage Humidity 85% non-condensing
DVI-I DUAL LINK 1
1
VGA 1
CVBS IN 1
CVBS OUT 1
RS232 IN 1
RS232 OUT 1
ISP IN 1
IR IN 1
CODING BUTTON 1
AC IN AC100-240V
Color System Support

PAL/NTSC/SECAM
Control Type IR Remote &Software Control
Menu Language English/Chinese(Multiple Language can be customized)



Service

Our customizable solutions offer a range of user-friendly features that streamline operation and enable the interconnectivity of your corporate control room, meeting rooms, and multi-screen display systems. Integrating a range of content types and signal formats, DDW’s multi screen video wall, control room display and digital signage systems can help you get your message across to customers more effectively.

5ms Response Time Surveillance video wall VGA AV YPBPR interface control room videowall DDW-LW550DUN-THA3 05ms Response Time Surveillance video wall VGA AV YPBPR interface control room videowall DDW-LW550DUN-THA3 1

DDW is one of leading manufacturer dedicated in R&D,manufacturing &selling commercial LCD displays especially LCD video wall systems for below fields: Conference and meeting rooms, office building, lobbies, security monitoring center, surveillance and retail center, restaurant and hotel, retail shopping mall advertising and information displays, public installations, exhibition and show center, live show, rental and advertising center,museums,church,transportation and mass info display systems.
