1.7mm SNB indoor screen operation center videowall 700nits brightness DDW-LW460HN13

Name: 1.7mm SNB indoor screen operation center videowall 700nits brightness DDW-LW460HN13
Brand: DDW
SKU: DDW-LW460HN13
Rating: 4.9 (200 reviews)

Product Details

Place of Origin: Guangdong , China (Mainland)

Brand Name: DDW

Certification: ISO9001 , CE , RoHS , FCC

Model Number: DDW-LW460HN13

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: First layer carton pack with filling foam , then wood pallet pack

Delivery Time: 3 working days upon payment

Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance

Supply Ability: 3 , 000pcs per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                hd video wall, samsung commercial displays


Panel Size:	46inch	Resolution:	1920 X 1080
Bezel Width:	1.7mm	Color:	8Bit , 16M
Brightness:	700nits	Surface:	Anti-glare
Backlight:	LED	Control Method:	RS232 Control
Signal Support:	DVI//VGA/AV/YPBPR	Working Time Capacity:	7x24hours

Panel Size:	46inch
Resolution:	1920 X 1080
Bezel Width:	1.7mm
Color:	8Bit , 16M
Brightness:	700nits
Surface:	Anti-glare
Backlight:	LED
Control Method:	RS232 Control
Signal Support:	DVI//VGA/AV/YPBPR
Working Time Capacity:	7x24hours

Product Description

1.7mm SNB indoor screen operation center videowall 700nits brightness DDW-LW460HN13

46" lcd video wall features:

Original Samsung Industrial grade LCD video wall screen, 16:9 Samsung a-Si TFT-LCD;
700nits brightness, 3500:1 contrast;
FHD physical resolution 1920x1080;
Only 1.7mm Ultra narrow bezel, high quality, practical, good vision effect;
Signal interface rich --- RS232, , DVI, VGA, YPbPr, AV;
HD video wall unit--- High brightness, high contrast, high gamut;
Flexible structure design ---easy installation, extensible, arbitrary combination;
Stable performance, suitable working for a long time;

Specifications

46 inch Samsung video wall specifications
LCD Technology	SAMSUNG DID LCD
Active Screen Diagonal	46"
Bezel Width	Total: 1.7mm
Aspect Ratio	16:9
Physical Resolution	1920*1080
Backlight System	LED
Luminance(nits)	700cd/sqm
Contrast	3500:1
Viewing Angle	H 178°\|V 178°
Pixel Pitch(WxH)	0.53025x0.53025mm
Active Display Area(WxH)	1018.08 × 572.67 mm
Panel Dimension(WxHxD)	1020.02x574.61x68.1mm
White Point	10,000 K
Display Colors	8Bit,16.7M
Refresh Rate	60Hz
Response Time	<=6ms
Life(hrs)	>60,000(hrs)
MTBF	> 100,000 h
Surface	Anti-glare
Standby Power Consumption	<3W
Maximum Power Consumption	lower than 220W
Power Supply	AC100~240V 50/60Hz
Cooling	Low noise fans
Heat Dissipation	819 BTU/h (max)
Working Time Capacity	7x24x365hours
Application Area	Indoor/Semi Outdoor
Working Temperature	0°C~50°C
Working Humidity	0.85
Storage Temperature	-20-60°C \| -4-140°F
Storage Humidity	85% non-condensing
DVI-I DUAL LINK	1
	1
VGA	1
CVBS IN	1
CVBS OUT	1
RS232 IN	1
RS232 OUT	1
ISP IN	1
IR IN	1
CODING BUTTON	1
AC IN	AC100-240V
Color System Support	PAL/NTSC/SECAM
Control Type	IR Remote &Software Control
Menu Language	English/Chinese(Multiple Language can be customized)
Vertical/Horizontal Display	Support
Combine Display	Support combine any horizental &vertical numbers of screens and show display
	Support combine all screens together to show 1image
Solid Display	Support each screen input with separate signal
PIP/Zoom/Roaming	Support open one window for each screen, each window can be zoomed &roaming internal freely
Multiple Interfaces	Support DVI,,VGA,AV &multiple signal inputs
Rich Resolution	Support 1080P,1080I,720P,480P &multiple resolution inputs
Dimension(WxHxD)	318.4x332x56mm
