Place of Origin: | Guangdong , China (Mainland) |
---|---|
Brand Name: | DDW |
Certification: | ISO9001 , CE , RoHS , FCC |
Model Number: | DDW-LW490DUN-THC1 |
Minimum Order Quantity: | 2pcs |
Price: | Negotiable |
Packaging Details: | First layer carton pack with filling foam , then wood pallet pack |
Delivery Time: | 3 working days upon payment |
Payment Terms: | T/T , Western , L/C Union , Alibaba trade assurance |
Supply Ability: | 3 , 000pcs per month |
Screen Size: | 49" | Resolution: | 1920 X 1080 |
---|---|---|---|
Bezel Width: | 3.5mm | Color: | 8Bit , 16M |
Brightness: | 500nits | Surface: | Anti-glare |
Backlight: | LED | Control Method: | RS232 Control |
Response Time: | 5ms | Input Voltage: | AC 110-240v |
Signal Support: | DVI//VGA/AV/YPBPR | Composite In Capacity: | Yes |
High Light: | control room displays,hd video wall |
3.5mm lg Video Wall 49 control room display with LED Backlight IR Remote Software Control DDW-LW490DUN-THC1
Key features
Specifications
Active Screen Diagonal | 49" | |||||||||
Bezel Width | Total: 3.5mm | |||||||||
Aspect Ratio | 16:9 | |||||||||
Physical Resolution | 1920*1080 | |||||||||
Backight System | LED | |||||||||
Luminance(nits) | 500cd/㎡ | |||||||||
Contrast | MEGA DCR | |||||||||
Viewing Angle | H 178°|V 178° | |||||||||
Pixel Pitch(WxH) | 0.5593x0.5593mm | |||||||||
Active Display Area(WxH) | 1073.8 × 604 mm | |||||||||
Panel Dimension(WxHxD) | 1077.6x607.8x55.6mm | |||||||||
White Point | 10,000 K | |||||||||
Display Colors | 8Bit,16.7M | |||||||||
Refresh Rate | 60Hz | |||||||||
Response Time | <=6ms | |||||||||
Life(hrs) | >60,000(hrs) | |||||||||
MTBF | > 100,000 h | |||||||||
Surface | Anti-glare | |||||||||
Standby Power Consumption | <3W | |||||||||
Maximum Power Consumption | ≦230W | |||||||||
Power Supply | AC100~240V 50/60 HZ | |||||||||
Cooling | Low noise fans | |||||||||
Heat Dissipation | 819 BTU/h (max) | |||||||||
Working Time Capacity | 7x24x365hours | |||||||||
Application Area | Indoor/Semi Outdoor | |||||||||
Working Temperature | 0℃~50℃ | |||||||||
Working Humidity | 0.85 | |||||||||
Storage Temperature | -20-60°C | -4-140°F | |||||||||
Storage Humidity | 85% non-condensing | |||||||||
Inputs, Outputs &Features | ||||||||||
DVI-I DUAL LINK | 1 | |||||||||
1 | ||||||||||
VGA | 1 | |||||||||
CVBS IN | 1 | |||||||||
CVBS OUT | 1 | |||||||||
RS232 IN | 1 | |||||||||
RS232 OUT | 2 | |||||||||
ISP IN | 1 | |||||||||
IR IN | 1 | |||||||||
CODING BUTTON | 1 | |||||||||
AC IN | AC100-240V | |||||||||
Color System Support | PAL/NTSC/SECAM | |||||||||
Control Type | IR Remote &Software Control | |||||||||
Menu Language | English/Chinese(Multiple Language can be customized) | |||||||||
Vertical/Horizontal Display | Support | |||||||||
Combine Display | Support combine any horizental &vertical numbers of screens and show display | |||||||||
Support combine all screens together to show 1image | ||||||||||
Solid Display | Support each screen input with separate signal | |||||||||
PIP/Zoom/Roaming | Support open one window for each screen, each window can be zoomed &roaming internal freely | |||||||||
Multiple Interfaces | Support DVI,,VGA,AV &multiple signal inputs | |||||||||
Rich Resolution | Support 1080P,1080I,720P,480P &multiple resolution inputs | |||||||||
Dimension(WxHxD) | 318.4x332x56mm |
DDW offers a range of scalable connectivity and display processing systems for corporate av applications, as well as large-scale multiscreen video wall solutions for enterprise-level installations. The remote capabilities and real-time signal processing provided by our conference, board, collaboration and control room display systems support multi-site workflows and critical decision-making.
Service
Our customizable solutions offer a range of user-friendly features that streamline operation and enable the interconnectivity of your corporate control room, meeting rooms, and multi-screen display systems. Integrating a range of content types and signal formats, DDW’s multi screen video wall, control room display and digital signage systems can help you get your message across to customers more effectively.
