49" LG 4K video surveillance control room screens Super narrow bezel DDW-LW490DUN-THC1

Name: 49" LG 4K video surveillance control room screens Super narrow bezel DDW-LW490DUN-THC1
Brand: DDW
SKU: DDW-LW490DUN-THC1
Rating: 4.6 (153 reviews)

Product Details

Place of Origin: Guangdong , China (Mainland)

Brand Name: DDW

Certification: ISO9001 , CE , RoHS , FCC

Model Number: DDW-LW490DUN-THC1

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: First layer carton pack with filling foam , then wood pallet pack

Delivery Time: 3 working days upon payment

Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance

Supply Ability: 3 , 000pcs per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                control room displays, hd video wall


Product Name:	Innolux Super Narrow Bezel Control Room Video Wall	Resolution:	3840 X 2160
Bezel Width:	3.5mm	Viewing Angle:	178 X 178
Brightness:	500nits	Surface:	Anti-glare
Backlight:	WLED	Control Method:	RS232 Control
Response Time:	5ms	Input Voltage:	AC 110-240v
Signal Support:	DVI//VGA/AV/YPBPR	Working Time Capacity:	7x24hours

Product Name:	Innolux Super Narrow Bezel Control Room Video Wall
Resolution:	3840 X 2160
Bezel Width:	3.5mm
Viewing Angle:	178 X 178
Brightness:	500nits
Surface:	Anti-glare
Backlight:	WLED
Control Method:	RS232 Control
Response Time:	5ms
Input Voltage:	AC 110-240v
Signal Support:	DVI//VGA/AV/YPBPR
Working Time Capacity:	7x24hours

Product Description

49" LG 4K video surveillance control room screens Super narrow bezel DDW-LW490DUN-THC1

DDW offers a range of scalable connectivity and display processing systems for corporate av applications, as well as large-scale multiscreen video wall solutions for enterprise-level installations. The remote capabilities and real-time signal processing provided by our conference, board, collaboration and control room display systems support multi-site workflows and critical decision-making.

Key features

1, Signal interface rich --- RS232, , DVI, VGA, YPbPr, AV;
2, HD video wall unit--- High brightness, high contrast, high gamut;
3, Flexible structure design ---easy installation, extensible, arbitrary combination;
4, Stable performance, suitable working for a long time;
5, Original Innolux commercial grade lcd video wall panel, 16:9 Innolux a-Si TFT-LCD;
6, 500nits brightness, 5000:1 contrast;
7, HD physical resolution 3840 x 2160;
8, only 3.5mm ultra narrow bezel, high quality, practical, good vision effect;

Service
Our customizable solutions offer a range of user-friendly features that streamline operation and enable the interconnectivity of your corporate control room, meeting rooms, and multi-screen display systems. Integrating a range of content types and signal formats, DDW’s multi screen video wall, control room display and digital signage systems can help you get your message across to customers more effectively.

Specifications

Panel Specifications
Active Screen Diagonal			49"
Total Bezel Width			3.5mm
Aspect Ratio			16:9
Physical Resolution			3840x2160
Backight System			LED
Luminance(nits)			500cd/㎡
Contrast			5000:1
Viewing Angle			H 178°\|V 178°
Pixel Pitch(WxH)			0.5593x0.5593mm
Active Display Area(WxH)			1073.8 × 604 mm
Panel Dimension(WxHxD)			1077.6x607.8x55.6mm
White Point			10,000 K
Display Colors			1.07GB colors
Refresh Rate			60Hz
Response Time			<=6ms
Life(hrs)			>60,000(hrs)
MTBF			> 100,000 h
Surface			Anti-glare
Standby Power Consumption			<3W
Maximum Power Consumption			≦160W
Power Supply			AC100~240V 50/60 HZ
Cooling			Low noise fans
Heat Dissipation			819 BTU/h (max)
Working Time Capacity			7x24x365hours
Application Area			Indoor/Semi Outdoor
Working Temperature			0℃～50℃
Working Humidity			0.85
Storage Temperature			-20-60°C \| -4-140°F
Storage Humidity			85% non-condensing
Inputs, Outputs &Features
DVI-I DUAL LINK			1
			1
VGA			1
CVBS IN			1
CVBS OUT			1
RS232 IN			1
RS232 OUT			1
ISP IN			1
IR IN			1
AC IN			AC100-240V
Color System Support			PAL/NTSC/SECAM
Control Type			IR Remote &Software Control
Menu Language			English/Chinese(Multiple Language can be customized)
Vertical/Horizontal Display			Support
Combine Display			Support combine any horizental &vertical numbers of screens and show display
			Support combine all screens together to show 1image
Solid Display			Support each screen input with separate signal
PIP/Zoom/Roaming			Support open one window for each screen, each window can be zoomed &roaming internal freely
Multiple Interfaces			Support DVI,,VGA,AV &multiple signal inputs
Rich Resolution			Support 1080P,1080I,720P,480P &multiple resolution inputs
