Exhibition LG Digital Signage HD Video Wall 500 Nits Brightness TV Screen 1920x1080

Exhibition LG Digital Signage HD Video Wall 500 Nits Brightness TV Screen 1920x1080

    • Exhibition LG Digital Signage HD Video Wall 500 Nits Brightness TV Screen 1920x1080
    • Exhibition LG Digital Signage HD Video Wall 500 Nits Brightness TV Screen 1920x1080
    • Exhibition LG Digital Signage HD Video Wall 500 Nits Brightness TV Screen 1920x1080
    • Exhibition LG Digital Signage HD Video Wall 500 Nits Brightness TV Screen 1920x1080
    • Exhibition LG Digital Signage HD Video Wall 500 Nits Brightness TV Screen 1920x1080
    • Exhibition LG Digital Signage HD Video Wall 500 Nits Brightness TV Screen 1920x1080
  • Exhibition LG Digital Signage HD Video Wall 500 Nits Brightness TV Screen 1920x1080

    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LW550DUN

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: Negotiable
    Packaging Details: First layer carton pack with filling foam , then wood pallet pack
    Delivery Time: 3 working days upon payment
    Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Panel Size: 55inch Resolution: 1920x1080
    Bezel Width: 1.8mm Color: 8Bit , 16M
    Brightness: 500nits Surface: Anti-glare
    Backlight: LED Control Method: RS232 Control

    Exhibition screens lg digital signage wall 500nits brightness video wall tv screens


    Parameters

    •  Original LG commercial grade lcd video wall display panel, 16:9 LG a-Si TFT-LCD
    •  700its brightness , MEGA DCR contrast
    •  FHD physical resolution 1920x1080
    •  Only 1.8mm Ultra narrow bezel , high quality , practical , good vision effect
    •  Signal interface rich , RS232 , HDMI , DVI , VGA , YPbPr , AV
    •  FHD video wall unit , high brightness , high contrast , high gamut
    •  Flexible structure design , easy installation , extensible , arbitrary combination
    •  Stable performance , suitable working for a long time

    Key features

    • Support a variety of signal ports
    • Built-in splicing module , Support splice function
    • Support Creating one window PIP across the screen , roaming service , scaling , PIP
    • Support matrix joint control
    • Unique DNX motion supplement image processing technology
    • Dynamic image without motion trail
    • Splicing image processing RS-232 RJ45 loop-circuit input/output
    • Input by remote control with wire , mobile receiver head

    Specifications

    Model No. DDW-LW550DUN
    LCD Technology LG a-Si TFT-LCD
    Active Screen Diagonal 55"
    Aspect Ratio 16:9
    Luminance(nits) 500cd/sqm
    Contrast 4000:1
    Viewing Angle H 178°/V 178°
    Pixel Pitch(WxH) 0.63×0.63mm
    Active Display Area(WxH) 1209.6×680.4 mm
    Panel Dimension(WxHxD) 1211.4x682.2x53.3mm
    White Point 10,000 K
    Display Colors 8Bit,16.7M
    Refresh Rate 60Hz
    Response Time <=6ms
    Life(hrs) >60,000(hrs)
    MTBF > 100,000 h
    Surface Anti-glare
    Standby Power Consumption <3W
    Maximum Power Consumption ≧ 250W
    Power Supply AC100~240V 50/60 HZ
    Cooling Low noise fans
    Heat Dissipation 819 BTU/h (max)
    Working Time Capacity 7x24x365hours
    Application Area Indoor/Semi Outdoor
    Working Temperature 0°C~50°C
    Working Humidity 0.85
    Storage Temperature -20-60°C | -4-140°F
    Storage Humidity 85% non-condensing
    HDMI 1
    VGA 1
    CVBS IN 1
    CVBS OUT 1
    ISP IN 1
    IR IN 1
    CODING BUTTON 1
    AC IN AC100-240V
    Color System Support PAL/NTSC/SECAM
    Control Type IR Remote &Software Control
    Menu Language English/Chinese(Multiple Language can be customized)
    Vertical/Horizontal Display Support
