IP65 Electric Vehicle Charging Stations Lcd Digital Signage Display DDW-ADO6501SN

IP65 Electric Vehicle Charging Stations Lcd Digital Signage Display DDW-ADO6501SN

    • IP65 Electric Vehicle Charging Stations Lcd Digital Signage Display DDW-ADO6501SN
    • IP65 Electric Vehicle Charging Stations Lcd Digital Signage Display DDW-ADO6501SN
    • IP65 Electric Vehicle Charging Stations Lcd Digital Signage Display DDW-ADO6501SN
    • IP65 Electric Vehicle Charging Stations Lcd Digital Signage Display DDW-ADO6501SN
    • IP65 Electric Vehicle Charging Stations Lcd Digital Signage Display DDW-ADO6501SN
  • IP65 Electric Vehicle Charging Stations Lcd Digital Signage Display DDW-ADO6501SN

    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC , IP65
    Model Number: DDW-ADO6501SN

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: Carton and Full wood box packing
    Delivery Time: 20-30working days upon payment
    Payment Terms: T/T , Western Union , L/C , Alibaba Trade Assurance
    Supply Ability: 300 set per month
    Contact Now
    Detailed Product Description
    Application: Outdoor Panel Brand: Samsung LG
    Storage Temperature: -40℃ — 50℃ Average Brightness: 1500-2500cd/m*m
    Maximum Resolution: 1920x1080 Maximum Power Consumption: 3600W
    Input Voltage: AC 110V-240V
    High Light:

    electric vehicle charging pile

    ,

    electric vehicle charging stations

    IP 65 Grade Charging Station Original Panel Lcd Digital Signage Display Electric Vehicle Charge Pile DDW-ADO6501SN



    Main Application:
    Applicable to public car parks, residential area, parking, private parking, and other businesses open yard with underground parking



    65 inch charge Pile digital signage functions:

    1.This product can be composed of human-computer interactive touch screen, 65-inch LCD screen, RF reader, energy measurement module, communication module, charging interface, control module and pile composition.


    2.Charging pile with multiple protection function, input and output with double safety protection measures, charging real-time monitoring of the connection of the charging cable status, connection abnormalities immediately terminate the charge to ensure that the charging process is safe for people and vehicles.


    3.User interface and display can be used to control the functions, so that customers can easily complete the charging process.



    4.external access is available for Ethernet, GPRS, WIFI, Bluetooth and other communication interface, and monitoring center, operation and management center real-time communication, real-time monitoring of charging status.

    Charge Pile digital signage key features:
    1 . 65 inch high brightness LCD Module , 1500-2500nits brightness , 1920x1080 resolution , 4000:1 contrast with LED backlight , Sunlight viewable
    2 . Patented LED backlight modular components + constant current source drive components
    3 . Patented cooling structure combination of high-quality fan assembly
    4 . Quad cores CPU 8Gb memory , Latest Android OS network version support LAN control , WIFI control , USB , CF , SD slots , support HDMI VGA input,3G(optional)
    5 . Automatic ambient light adjustment control (extended life and energy efficiency)
    6 . Built-in power adapter combination AC 220V/DC
    7 . IP65 grade all waterproof and dustproof metal enclosure +6mm optical protective glass + air cooling/heating system
    8 . Highly fortified AR glass , protect the LCD screen from direct injury , played the role of anti-riot
    9 . Rackmount LCD display module + built-in anti-theft locks , patented a unique , easy to disassemble and maintain the site , a unique patent
    10 . A/C automatic fans Cooling/Heating system , thickness 14cm , Intelligent condition monitoring,real-time detection equipment vibration , temperature and humidity parameters such as power supply , timely warning , Working temperature: -40℃ - 50℃
    11 . Frame(fit with single side screen) can be customized exactly same as client provided

    Outdoor Charge Pile digital signage Parameters

    LCD parameters

    display

    65" LED

    Contrast Ratio

    16:9

    Maximum resolution

    1920x1080

    Display color

    1.073G(10bits/color)

    Life(hrs)

    >60,000(hrs)

    average brightness

    1500-2500cd/m*m

    contrast

    4000:1

    Viewing angle

    H178°/V178°

    Power supply

    AC100~240V 50 /60 HZ

    Maximum power consumption

    3600W

    Standby power consumption

    <5W

    Working temperature

    0- 40 ℃

    Storage temperature

    -40℃ — 50℃

    Installation

    flood-standing, wall mounted or customized

    IP65 waterproof case

    Using 1.5mm galvanized steel

    Surface spray powder (anti-corrosion, anti-rust)

    Outdoor anticorrosive over 7 years

    AR anti-reflective glass 3 + 3mm plastic folder

    Display screen glass

    Light transmittance 97%

    Reflectivity is less than 3%

    Explosion-proof, waterproof, fireproof

    UV protection 99%

    Display screen

    Industrial-grade LED, Original Samsung screen,brightness 2000cd / m2

    High brightness 1500-2000 cd/㎡

    Full hd 1920 x1080

    Industrial power supply

    automatically adjust the brightness

    Electronic control system

    Power supplies , timers , remote control panel , photographic plate , speaker , battery , leakage protection switches , sockets , etc.

    Cooling system

    Intelligent heating and air-cooling system

    meet the environment of -20℃ — 55 ℃

    LCD display is not blackening

    Patented cooling system ensures that the LCD screen without blackening in direct sunlight

    Product assembly and aging test

    IP65 waterproof test

    High and low temperature test

    Simulated solar radiation test

    Aging test

    Packaging

    Wooden packaging , sea/air/express(transportation standards)

    IP65 Electric Vehicle Charging Stations Lcd Digital Signage Display DDW-ADO6501SN

    IP65 Electric Vehicle Charging Stations Lcd Digital Signage Display DDW-ADO6501SN
