1.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor

Name: 1.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor
Brand: DDW
SKU: DDW-LW460HN13
Rating: 4.8 (184 reviews)

Product Details

Place of Origin: Guangdong , China (Mainland)

Brand Name: DDW

Certification: ISO9001 , CE , RoHS , FCC

Model Number: DDW-LW460HN13

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: First layer carton pack with filling foam , then wood pallet pack

Delivery Time: 3 working days upon payment

Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance

Supply Ability: 3 , 000pcs per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                interactive video display, interactive wall display


Diagonal Size:	46"	Total Physical Bezel:	1.7mm
Resolution:	1920*1080	Product Name:	Interactive Video Wall
Panel Width:	1020.02 Mm	Panel Height:	574.61 Mm
Backight System:	LED	Contrast:	MEGA DCR

Diagonal Size:	46"
Total Physical Bezel:	1.7mm
Resolution:	1920*1080
Product Name:	Interactive Video Wall
Panel Width:	1020.02 Mm
Panel Height:	574.61 Mm
Backight System:	LED
Contrast:	MEGA DCR

Product Description

LW460HN13 1.7mm Interactive Video Wall 1920*1080 700 nits 1020.02mm 574.61mm

Interactive Video Wall Features

Support a variety of signal ports
Built-in splicing module , Support splice function
Support creating one window PIP across the screen , roaming service , scaling , PIP
Support matrix joint control
Unique DNX motion supplement image processing technology
Dynamic image without motion trail
Splicing image processing RS-232 RJ45 loop-circuit input/output
Input by remote control with wire , mobile receiver head

Description

DDW offers a range of scalable connectivity and display processing systems for corporate av applications, as well as large-scale multiscreen video wall solutions for enterprise-level installations. The remote capabilities and real-time signal processing provided by our conference, board, collaboration and control room display systems support multi-site workflows and critical decision-making.

46inch Interactive Video Wall Parameters

Original DDW commercial grade lcd video wall display panel , 16:9 TFT-LCD
700its brightness , MEGA DCR contrast.FHD video wall unit , high brightness , high contrast , high gamut
FHD 1.7mm Ultra narrow bezel , high quality , practical , good vision effect
Interface: 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output
Flexible structure design , easy installation , extensible , arbitrary combination
Stable performance , suitable working for a long time

Specifications

Model No.	DDW-LW460HN13
Active Screen Diagonal	46''
Bezel Width	Total: 1.7mm
Aspect Ratio	16:9
Physical Resolution	1920x1080
Backight System	LED
Luminance(nits)	700cd/sqm
Contrast	MEGA DCR
Viewing Angle	H 178°\|V 178°
Panel Dimension(WxHxD)	1020.02×574.61x68.1mm
White Point	10,000 K
Display Colors	8Bit,16.7M
Refresh Rate	60Hz
Response Time	<=6ms
Life(hrs)	>60,000(hrs)
MTBF	> 100,000 h
Surface	Anti-glare
Standby Power Consumption	<3W
Maximum Power Consumption	lower than 250W
Power Supply	AC100~240V 50/60 HZ
Cooling	Low noise fans
Heat Dissipation	819 BTU/h (max)
Working Time Capacity	7x24x365hours
Application Area	Indoor/Semi Outdoor
Working Temperature	0°C~50°C
Working Humidity	0.85
Storage Temperature	-20-60°C \| -4-140°F
Storage Humidity	85% non-condensing

Interactive Video Wall Board Specifications

Support	PC	Color	24bit
Signal		Line synchronization range	30-80KHZ
		Field synchronization range	50-75HZ
	DVI HDMI DP	Color	24bit
		Line synchronization range	30-80KHZ
		Field synchronization range	50-75HZ
Interface	Input	VGA x 1	15pin D-Sub
		DVI x 1	DVI-I
		DP x 1	Display Port
		HDMI x 2	HDMI-19 pin
	Output	PANEL	LVDS 36Pin/2.0
	Output	DP out	DP loop out
Power	Input power	DC24V/12V/5V
	Drive panel	5V/12V
	Power mode	Normal working mode, power saving mode
Other	OSD	Chinese, English and other languages (other languages can be added as required)
