Wall - Mounted 3x3 Video Wall , 1080P UHD Vertical Video Wall 49 Inch
Product Details:
| Place of Origin: | Guangdong , China (Mainland) |
| Brand Name: | DDW |
| Certification: | ISO9001 , CE , RoHS , FCC |
| Model Number: | DDW-DV490FHM-NV0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | First layer carton pack with filling foam , then wood pallet pack |
| Delivery Time: | 3 working days upon payment |
| Payment Terms: | T/T , Western , L/C Union , Alibaba trade assurance |
| Supply Ability: | 3 , 000pcs per month |
|
Detail Information |
|||
| Name: | 3x3 Video Wall | Bezel Width: | 3.5 Mm |
|---|---|---|---|
| Surface: | Anti-glare | Brightness: | 500 Nits |
| Mount: | Wall - Mounted | Panel Brand: | BOE |
| Panel Width: | 1077.6 Mm | Panel Height: | 607.8 Mm |
| Highlight: | multi display video wall,seamless lcd video wall |
||
Product Description
Wall - Mounted 3x3 Video Wall , 1080P UHD Vertical Video Wall 49 Inch
3x3 Video Wall Key features
- Original DDW commercial grade lcd video wall panel, 16:9 INNOLUX a-Si TFT-LCD
- 500nits brightness , 4000:1 contrast.UHD video wall unit , high brightness, high contrast, high gamut
- Only 3.5 mm narrow bezel , high quality , practical , good vision effect
- Flexible structure design , easy installation , extensible , arbitrary combination
3x3 Video Wall Applications
3x3 Video Wall is the best cost-effective model , which can be widely used for cctv control room conference and meeting rooms , gym center , lobbies , security monitoring center , surveillance and retail center , restaurant and hotel , retail shopping mall advertising and information displays , public installations , exhibition and show center , live show , rental and advertising center , museums , church , transportation and mass info display systems.
3x3 Video Wall Specifications
| Model No: | DDW-DV490FHM-NV0 3x3 Video Wall |
| Active Screen Diagonal | 49" |
| TotalBezel Width | 3.5 mm |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920x1080 |
| Backight System | LED |
| Luminance(nits) | 500 cd/sqm |
| Contrast | MEGA DCR |
| Viewing Angle | H 178°|V 178° |
| Panel Dimension(WxHxD) |
1077.6x607.8x59.67mm |
| White Point | 10,000 K |
| Display Colors | 8Bit,16.7M |
| Refresh Rate | 60Hz |
| Response Time | <=6ms |
| Life(hrs) | >60,000(hrs) |
| MTBF | > 100,000 h |
| Surface | Anti-glare |
| Standby Power Consumption | <3W |
| Maximum Power Consumption | lower than 250W |
| Power Supply | AC100~240V 50/60 HZ |
| Cooling | Low noise fans |
| Heat Dissipation | 819 BTU/h (max) |
| Working Time Capacity | 7x24x365hours |
| Application Area | Indoor/Semi Outdoor |
| Working Temperature | 0°C~50°C |
| Working Humidity | 0.85 |
| Storage Temperature | -20-60°C | -4-140°F |
| Storage Humidity | 85% non-condensing |
3x3 Video Wall basic informations:
- With original LG, Samsung panel, has a stylish design, lighter weight, easy to handle and install;
- Adapting modular components, making maintenance operations and parts replacement very easily;
- The installation method: front push hydraulic pop out;
- Dot Pitch: 0.5595 mm x 0.5595 mm; Contrast ratio: 4000:1; Responsive time: 6ms;
- Panel life: above 50000 hours; Certificate: FCC, CE, ROHS, IP65; Warranty: 1 year
3x3 Video Wall Board Specifications
| Support | PC | Color | 24bit |
| Interface | Input | VGA x 1 | 15pin D-Sub |
| DVI x 1 | DVI-I | ||
| DP x 1 | Display Port | ||
| HDMI x 2 | HDMI-19 pin | ||
| Output | PANEL | LVDS 36Pin/2.0 | |
| DP out | DP loop out | ||
| Power | Input power | DC24V/12V/5V | |
| Drive panel | 5V/12V | ||
| Power mode | Normal working mode, power saving mode | ||
| Other | OSD | Chinese, English and other languages (other languages can be added as required) |
|
