SHENZHEN DDW TECHNOLOGY CO.,LTD Company Profile
products
Home > products > LCD Video Wall > DDW Digital Samsung Video Wall Screens / Bright Outdoor 3x2 Video Wall
DDW Digital Samsung Video Wall Screens / Bright Outdoor 3x2 Video Wall
DDW Digital Samsung Video Wall Screens / Bright Outdoor 3x2 Video Wall
DDW Digital Samsung Video Wall Screens / Bright Outdoor 3x2 Video Wall

DDW Digital Samsung Video Wall Screens / Bright Outdoor 3x2 Video Wall

Product Details

Place of Origin: Guangdong , China (Mainland)

Brand Name: DDW

Certification: ISO9001 , CE , RoHS , FCC

Model Number: DDW-LW460HN11

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: First layer carton pack with filling foam , then wood pallet pack

Delivery Time: 3 working days upon payment

Payment Terms: L/C , L/C , T/T

Supply Ability: 3 , 000pcs per month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

conference room video wall

,

control room displays

Product Name:
Samsung Video Wall Screens
Control Method:
RS232 Control
Total Physical Bezel:
3.5 Mm
Type:
Digital
Backlit Type:
LED
Panel Width:
1021.98mm
Panel Height:
576.57mm
Size:
3x2 Video Wall
Product Name:
Samsung Video Wall Screens
Control Method:
RS232 Control
Total Physical Bezel:
3.5 Mm
Type:
Digital
Backlit Type:
LED
Panel Width:
1021.98mm
Panel Height:
576.57mm
Size:
3x2 Video Wall
Product Description

DDW Digital Samsung Video Wall Screens / Bright Outdoor 3x2 Video Wall



Samsung Video Wall Screens informations:

  •  With original LG, Samsung panel, has a stylish design, lighter weight, easy to handle and install;
  •  Adapting modular components, making maintenance operations and parts replacement very easily;
  •  The installation method: floor standing cabinets;
  •  Dot Pitch: 0.532mm(H)*0.5302mm(W); Contrast ratio: 4000:1; Responsive time: 6ms;
  •  Panel life: above 50000 hours; Certificate: FCC, CE, ROHS, IP65; Warranty: 1 year;

Samsung Video Wall ScreensFunctions:

  •  Supporting 225 units (15×15) multi-matrix;
  •  Single screen display. Each unit can display the picture independently;
  •  Image overlay. Superimposed on screen another picture;
  •  Easy to choose full screen or multi-screen display by control video wall controller.

Samsung Video Wall Screens Specifications



LCD Technology Samsung a-Si TFT-LCD
Active Screen Diagonal 46''
Panel Dimension(WxHxD)

1021.98x576.57x72.1mm
Total Bezel Width 3.5mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backlight System LED
Luminance(nits) 500cd/sqm
Contrast 5000:1 (typ.)
Viewing Angle H 178°|V 178°
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption <=250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor/Outdoor
Working Temperature 0°C~50°C
Working Humidity 85% non-condensing
Storage Temperature -20-60°C | -4-149°F
Storage Humidity 85% non-condensing



Samsung Video Wall Screens Board Specifications

Support PC Color 24bit
Signal   Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ

DVI

HDMI

DP

 Color 24bit
Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ
Power Input power DC24V/12V/5V
Drive panel 5V/12V
Power mode Normal working mode, power saving mode
Other OSD Chinese, English and other languages (other languages can be added as required)



DDW Digital Samsung Video Wall Screens / Bright Outdoor 3x2 Video Wall 0
