4 Split Screen Video Matrix Processor , DIV 3G-SDI Signal Output 2x3 Video Wall Controller Matrix
Product Details:
| Place of Origin: | Guangdong, China (Mainland) |
| Brand Name: | DDW |
| Certification: | ISO9001 ,CE , RoHS , FCC , 3C |
| Model Number: | DDW-VM7168 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set/Sets |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Double layer carton pack |
| Delivery Time: | 3working days upon payment |
| Payment Terms: | T/T,L/C,Western Union,Alibaba Trade Assurance |
| Supply Ability: | 1000pcs/month |
|
Detail Information |
|||
| Maximum Input Numbers: | 71 | Maximum Output Numbers: | 68 |
|---|---|---|---|
| Output Resolution: | 1920*1080 | Max PIP Per Screen: | 1,4,16,customization |
| Product Name: | Video Wall Matrix | Input Bandwidth: | 165MHZ |
| Input Output Signal Sources: | HDMI,DVI,VGA,AV,YPBPR,IP | Control Method: | RS232,LAN |
| Highlight: | video wall multiplexer,multi screen video controller |
||
Product Description
4 Split Screen LG Video Wall Matrix Support DIV And 3G - SDI Signal Output
LCD Video Wall Matrix key features:
- With special virtual display technology, full channel real HD 1080P signal processing;
- Signal Preview function available;
- Supporting PC, Android APK, iOS APP control software;
- Image parameters( white balance, brightness, contrast, saturation) can be adjusted;
- Scaling and positioning, size is scalable and position adjustable;
- With background logo display function. It can be customized;
- Applications: company meeting, monitoring, exhibition, public security, railway, military, meteorological, aviation, market, museum; monitoring, command and scheduling systems, public security, railway, military, meteorological, aviation;
Simplified installation & disassembly
- Flexible modular design, Input and output card board;
- Support input of a variety of interfaces and signal source;
- Matching features, pre-monitoring;
- Echo function, input and output characters display with superimposed;
Pure hardware architecture board any combination:
- Industrial chassis with CPCI structure;
- Modular design, dual backup redundant power supply support hot backup, fan and other modules at will;
- Supporting the system processing module hot-swappable, provide various types of chassis and board, for customers to save costs;
DDW Video Wall Matrix Technical Specifications
| Model No. | DDW-VM7168 | |||||||||
| Quotation | ||||||||||
| Item No. | Components | Descriptions | QTY/signal | signal type | ||||||
| 1 | Video wall Matrix SwitcherDDW-VM7168 | 71HDMI input ,68HDMI output , pure hardware , support multiple splicing player freely , and can show different sigal at the same time to the system,require screen built in daisy chain board | 139 | HDMI | ||||||
| 2 | Software | Installed in PC to control,OS windows | 1 | |||||||
| 3 | Accessories | Power plug,IR Controller,English Manual | 1 | |||||||
| input card | ||||||||||
| interface | 71*HDMI type a | |||||||||
| signal protocal | HDMI 1.3, HDCP 1.3, compatible DVI1..0 | |||||||||
| EDID | support | |||||||||
| input bandwidth | 165MHZ | |||||||||
| resolution | HDTV 1920*1080@60HZ, HDCP 1920*1200@60HZ | |||||||||
| output card | ||||||||||
| interface | 68*HDMI type a | |||||||||
| signal protocal | HDMI 1.3, VGA 1.0, compatible DVI1..0 | |||||||||
| output bandwidth | 165MHZ | |||||||||
| output resolution |
1920x1200@60Hz,1920x1080@60Hz,1680x1050@60Hz,1600x1200@60Hz, 1600x900@60Hz,1440x900@60Hz,1400x1050@60Hz,1366x768@60Hz, 1280x1024@60Hz,1280x960@60Hz,1280x800@60Hz,1280x720@60Hz, 1024x768@60Hz,800x600@60Hz |
|||||||||
| switch effect | seamless switching | |||||||||
| System function | ||||||||||
| RS232 IN | 1 | |||||||||
| IR IN | 1 | |||||||||
| AC IN | AC100-240V | |||||||||
| Color System Support | PAL/NTSC/SECAM | |||||||||
| Control Type | IR Remote &Software Control | |||||||||
| Menu Language | English/Chinese(Multiple Language can be customized) | |||||||||
| Vertical/Horizontal Display | Support | |||||||||
| Combine Display | Support combine any horizental &vertical numbers of screens and show display | |||||||||
| Support combine all screens together to show one image | ||||||||||
| Solid Display | Support each screen input with separate signal | |||||||||
| PIP/Zoom/Roaming | NO | |||||||||
| Multiple Interfaces | Support DVI,HDMI,VGA,AV &multiple signal inputs | |||||||||
| Rich Resolution | Support 1080P,1080I,720P,480P &multiple resolution inputs | |||||||||
| Payment Terms &Conditions | ||||||||||
| Warranty: 3years warranty,extra fee will be charged for additional years warranty. | ||||||||||
