Home > products > LCD Video Wall > Slim bezel monitor LG video wall 46inch , led backlit 1.7mm wall display commercial

Slim bezel monitor LG video wall 46inch , led backlit 1.7mm wall display commercial

Product Details

Place of Origin: Guangdong , China (Mainland)

Brand Name: DDW

Certification: ISO9001 , CE , RoHS , FCC

Model Number: DDW-LW460HN14

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: First layer carton pack with filling foam , then wood pallet pack

Delivery Time: 3 working days upon payment

Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance

Supply Ability: 3 , 000pcs per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                video display walls, hd video wall


Panel Size:	46inch	Resolution:	1920x1080
Bezel Width:	1.7mm	Contrast Ratio:	MEGA DCR
Brightness:	500nits	Response Time:	5ms
Backlight:	LED	Viewing Angle:	178x178

Panel Size:	46inch
Resolution:	1920x1080
Bezel Width:	1.7mm
Contrast Ratio:	MEGA DCR
Brightness:	500nits
Response Time:	5ms
Backlight:	LED
Viewing Angle:	178x178

Product Description

Slim bezel monitor LG video wall 46inch , led backlit 1.7mm wall display commercial

Parameters
1, Original LG commercial grade lcd video wall display panel, 16:9 LG a-Si TFT-LCD;
2, 500its brightness, MEGA DCR contrast;
3, FHD physical resolution 1920x1080;
4, Only 1.7mm Ultra narrow bezel, high quality, practical, good vision effect;
5, Signal interface rich, RS232, , DVI, VGA, YPbPr, AV;
6, FHD video wall unit, high brightness, high contrast, high gamut;
7, Flexible structure design, easy installation, extensible, arbitrary combination;
8, Stable performance, suitable working for a long time;

Key features

Support a variety of signal ports
Built-in splicing module , Support splice function
Support Creating one window PIP across the screen , roaming service , scaling , PIP
Support matrix joint control
Unique DNX motion supplement image processing technology
Dynamic image without motion trail
Splicing image processing RS-232 RJ45 loop-circuit input/output
Input by remote control with wire , mobile receiver head

Slim bezel monitor LG video wall 46inch , led backlit 1.7mm wall display commercial 0

Specifications

Model No.	DDW-LW460HN14
LCD Technology	LG a-Si TFT-LCD
Active Screen Diagonal	46"
Total Bezel Width	1.7mm
Aspect Ratio	16:9
Physical Resolution	1920x1080
Backight System	WLED
Luminance(nits)	500cd/sqm
Contrast	MEGA DCR
Viewing Angle	H 178°/V 178°
Pixel Pitch(WxH)	0.5302x0.5302mm
Active Display Area(WxH)	1018.08×572.67mm
Panel Dimension(WxHxD)	1020.02x574.61x68mm
White Point	10,000 K
Display Colors	8Bit,16.7M
Refresh Rate	60Hz
Response Time	<=6ms
Life(hrs)	>60,000(hrs)
MTBF	> 100,000 h
Surface	Anti-glare
Standby Power Consumption	<3W
Maximum Power Consumption	≧250W
Power Supply	AC100~240V 50/60 HZ
Cooling	Low noise fans
Heat Dissipation	819 BTU/h (max)
Working Time Capacity	7x24x365hours
Application Area	Indoor/Semi Outdoor
Working Temperature	0°C~50°C
Working Humidity	0.85
Storage Temperature	-20-60°C \| -4-140°F
Storage Humidity	85% non-condensing
	1
VGA	1
CVBS IN	1
CVBS OUT	1
RS232 IN	1
RS232 OUT	1
ISP IN	1
IR IN	1
CODING BUTTON	1
AC IN	AC100-240V
Color System Support	PAL/NTSC/SECAM
Control Type	IR Remote &Software Control
Menu Language	English/Chinese(Multiple Language can be customized)
Vertical/Horizontal Display	Support
Combine Display	Support combine any horizontal &vertical numbers of screens and show display
Combine Display	Support combine all screens together to show 1image
Solid Display	Support each screen input with separate signal
PIP/Zoom/Roaming	Support open one window for each screen, each window can be zoomed &roaming internal freely
Multiple Interfaces	Support DVI,,VGA,AV &multiple signal inputs
Rich Resolution	Support 1080P,1080I,720P,480P &multiple resolution inputs

Various video wall control board options

Slim bezel monitor LG video wall 46inch , led backlit 1.7mm wall display commercial 1

Slim bezel monitor LG video wall 46inch , led backlit 1.7mm wall display commercial 2
