Full HD lg video wall 500nits high brightness lg digital signage 1920 x 1080 resolution DDW-LW490DUN-TJB1

Product Details

Place of Origin: Guangdong , China (Mainland)

Brand Name: DDW

Certification: ISO9001 , CE , RoHS , FCC

Model Number: DDW-LW490DUN-TJB1

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: First layer carton pack with filling foam , then wood pallet pack

Delivery Time: 3 working days upon payment

Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance

Supply Ability: 3 , 000pcs per month

Get Best Price
Product Details
Highlight:

hd video wall

,

narrow bezel video wall

Panel Size:
49inch
Resolution:
1920x1080
Bezel Width:
1.8mm
Color:
8Bit , 16M
Brightness:
800nits
Surface:
Anti-glare
Backlight:
LED
Control Method:
RS232 Control
Panel Size:
49inch
Resolution:
1920x1080
Bezel Width:
1.8mm
Color:
8Bit , 16M
Brightness:
800nits
Surface:
Anti-glare
Backlight:
LED
Control Method:
RS232 Control
Product Description

Full HD lg video wall 500nits high brightness lg digital signage 1920 x 1080 resolution DDW-LW490DUN-TJB1



Features


1, Original LG commercial grade lcd video wall display panel, 16:9 LG a-Si TFT-LCD
2, 500its brightness , MEGA DCR contrast
3, FHD 1.8mm Ultra narrow bezel , high quality , practical , good vision effect
5, Signal interface rich , RS232 , , DVI , VGA , YPbPr , AV
6, FHD video wall unit , high brightness , high contrast , high gamut
7, Flexible structure design , easy installation , extensible , arbitrary combination
8, Stable performance , suitable working for a long time



Full HD lg video wall 500nits high brightness lg digital signage 1920 x 1080 resolution DDW-LW490DUN-TJB1 0



Descriptions



  • Support a variety of signal ports
  • Built-in splicing module , Support splice function
  • Support Creating one window PIP across the screen , roaming service , scaling , PIP
  • Support matrix joint control
  • Unique DNX motion supplement image processing technology
  • Dynamic image without motion trail
  • Splicing image processing RS-232 RJ45 loop-circuit input/output
  • Input by remote control with wire , mobile receiver head





Specifications



Panel Specifications
LCD Technology LG a-Si TFT-LCD
Active Screen Diagonal 49" (1168 mm)
Bezel Width Total: 1.8mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backight System WLED
Luminance(nits) 500cd/sqm
Contrast MEGA DCR
Viewing Angle H 178°|V 178°
Pixel Pitch(WxH) 0.5593x0.5593mm
Active Display Area(WxH) 1073.8 × 604 mm
Panel Dimension(WxHxD) 1075.38x605.8x53.6mm
White Point 10,000 K
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000 h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption lower than 250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor
Working Temperature 0°C~50°C
Working Humidity 0.85
Storage Temperature -20-60°C | -4-140°F
Storage Humidity 85% non-condensing
1
VGA 1
CVBS IN 1
CVBS OUT 1
RS232 IN 1
RS232 OUT 1
ISP IN 1
IR IN 1
CODING BUTTON 1
AC IN AC100-240V
Color System Support PAL/NTSC/SECAM
Control Type IR Remote &Software Control
Menu Language English/Chinese(Multiple Language can be customized)
Vertical/Horizontal Display Support
Combine Display Support combine any horizontal &vertical numbers of screens and show display
Support combine all screens together to show 1image
Solid Display Support each screen input with separate signal
PIP/Zoom/Roaming Support open one window for each screen, each window can be zoomed &roaming internal freely
Multiple Interfaces Support DVI,,VGA,AV &multiple signal inputs
Rich Resolution Support 1080P,1080I,720P,480P &multiple resolution inputs

Full HD lg video wall 500nits high brightness lg digital signage 1920 x 1080 resolution DDW-LW490DUN-TJB1 1Full HD lg video wall 500nits high brightness lg digital signage 1920 x 1080 resolution DDW-LW490DUN-TJB1 2
