55 inch 3.5 mm 700nits LG seamless LCD video wall for fashion store advertising DDW-LW550HN12

Product Details

Place of Origin: Guangdong , China (Mainland)

Brand Name: DDW

Certification: ISO9001 , CE , RoHS , FCC

Model Number: DDW-LW550HN12

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: First layer carton pack with filling foam , then wood pallet pack

Delivery Time: 3 working days upon payment

Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance

Supply Ability: 3 , 000pcs per month

Get Best Price
Product Details
Highlight:

video display walls

,

hd video wall

Product Name:
LG LCD Video Wall
Installation:
Customized
Bezel Width:
3.5mm
Brightness:
700 Nits
ISM Method:
Normal , Orbiter , Inversion , White Wash
Backlight:
LED
Control Method:
RS232 Control
Signal Support:
DVI//VGA/AV/YPBPR
DPM Select:
Yes
Panel Brand:
LG IP
Application Condition:
Retail Shopping Mall
Product Name:
LG LCD Video Wall
Installation:
Customized
Bezel Width:
3.5mm
Brightness:
700 Nits
ISM Method:
Normal , Orbiter , Inversion , White Wash
Backlight:
LED
Control Method:
RS232 Control
Signal Support:
DVI//VGA/AV/YPBPR
DPM Select:
Yes
Panel Brand:
LG IP
Application Condition:
Retail Shopping Mall
Product Description

55 inch 3.5 mm 700nits LG seamless LCD video wall for fashion store advertising DDW-LW550HN12



55 inch 3.5 mm 700nits LG seamless LCD video wall for fashion store advertising DDW-LW550HN12 0



55 " LCD video wall main parameters

  • Original LG commercial grade lcd video wall display panel,16:9 LG a-Si TFT-LCD
  • 700 nits brightness,MEGA DCR contrast
  • FHD physical resolution 1920x1080
  • Only 3.5mm Ultra narrow bezel, high quality ,Practical ,good vision effect.
  • Signal interface rich --- RS232, ,DVI,VGA,Y Pb Pr ,AV
  • HD video wall unit--- High brightness,high contrast,High gamut .
  • Flexible structure design ---easy installation ,extensible,arbitrary combination
  • Stable performance,suitable working for a long time



Key features:

  1. Support a variety of signal ports.
  2. Built-in splicing module, Support splice function
  3. Support Creating one window PIP across the screen, roaming service, scaling,PIP
  4. Support matrix joint control.
  5. Unique DNX motion supplement image processing technology,
  6. Dynamic image without motion trail
  7. Splicing image processing RS-232 RJ45 loop-circuit input/output.
  8. Input by remote control with wire, mobile receiver head.



LG Video wall is one of LG most popular ultra narrow bezel lcd video wall panels. With 3.5mm ultra narrow bezel, LED backlight and FHD 1080P resolution, it can be widly used in below fields: Conference and meeting rooms, office building, lobbies, security monitoring center, surveillance and retail center, restaurant and hotel, retail shopping mall advertising and information displays, public installations, exhibition and show center, live show, rental and advertising center,museums,church,transportation and mass info display systems.



Specifications

Model No: DDW-LW550HN12
LCD Technology LG a-Si TFT-LCD
Active Screen Diagonal 55"
Pixel Pitch(WxH) 0.630x0.630mm
Active Display Area(WxH) 1209.6 × 680.4 mm
Panel Dimension(WxHxD)

1213.5x684.3x67.7mm

Total Bezel Width 3.5mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backlight System WLED
Luminance(nits) 700cd/sqm
Contrast 5000:1 (typ.)
Viewing Angle H 178°|V 178°
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption <=250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor/Outdoor
Working Temperature 0°C~50°C
Working Humidity 85% non-condensing
Storage Temperature -20-60°C | -4-149°F
Storage Humidity 85% non-condensing
DVI-I DUAL LINK 1
1
VGA 1
CVBS IN 1
CVBS OUT 1
RS232 IN 1
RS232 OUT 1
ISP IN 1
IR IN 1
CODING BUTTON 1



Various video wall control board options

55 inch 3.5 mm 700nits LG seamless LCD video wall for fashion store advertising DDW-LW550HN12 1

55 inch 3.5 mm 700nits LG seamless LCD video wall for fashion store advertising DDW-LW550HN12 2
