Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160

Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160

    • Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160
    • Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160
    • Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160
    • Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160
  • Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160

    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LW460HN13

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: Negotiable
    Packaging Details: First layer carton pack with filling foam , then wood pallet pack
    Delivery Time: 3 working days upon payment
    Payment Terms: L/C , L/C , T/T
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Signal Support: DVI/HDMI/VGA Resolution: 3840x2160
    Viewing Angle: 178x178 Brightness: 700nits
    Working Time Capacity: 7x24hours Input Voltage: AC 220v-250v
    Power Consumption: 230W

    Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160





    Key features

    1, Original INNOLUX commercial grade lcd video wall panel, 16:9 INNOLUX a-Si TFT-LCD;

    2, 700nits brightness, 4000:1 contrast;

    3, 4K UHD physical resolution 3840x2160;

    4, Only 1.7mm narrow bezel, high quality, practical, good vision effect;

    5, UHD video wall unit, high brightness, high contrast, high gamut;

    6, Flexible structure design, easy installation, extensible, arbitrary combination;



    Quick Detail

    1. RS232 control method;
    2. RJ45 loop Daisy chain video wall;
    3. Support DVI HDMI VGA AV YPBPR signals;
    4. Suitable working for 7x24hours;

    Applications

    This 46inch 1.7mm narrow bezel video wall is the best cost-effective model , which can be widely used for CCTV control room, conference and meeting rooms, office building, lobbies, security monitoring center, surveillance and retail center, restaurant and hotel, retail shopping mall advertising and information displays, public installations, exhibition and show center, live show, rental and advertising center,museums,church,transportation and mass info display systems.



    Specifications

    Model No: DDW-LW460HN13
    LCD Technology INNOLUX a-Si TFT-LCD
    Active Screen Diagonal 46"
    Total Bezel Width 1.7mm
    Aspect Ratio 16:9
    Physical Resolution 3840x2160
    Backight System WLED
    Luminance(nits) 700cd/sqm
    Contrast MEGA DCR
    Viewing Angle H 178°|V 178°
    Pixel Pitch(WxH) 0.5302x0.5302mm
    Active Display Area(WxH) 1018.08 × 572.67 mm
    Panel Dimension(WxHxD) 1020.02x574.61x68.1mm
    White Point 10,000 K
    Display Colors 8Bit,16.7M
    Refresh Rate 60Hz
    Response Time <=6ms
    Life(hrs) >60,000(hrs)
    MTBF > 100,000 h
    Surface Anti-glare
    Standby Power Consumption <3W
    Maximum Power Consumption lower than 250W
    Power Supply AC100~240V 50/60 HZ
    Cooling Low noise fans
    Heat Dissipation 819 BTU/h (max)
    Working Time Capacity 7x24x365hours
    Application Area Indoor/Semi Outdoor
    Working Temperature 0°C~50°C
    Working Humidity 0.85
    Storage Temperature -20-60°C | -4-140°F
    Storage Humidity 85% non-condensing
    HDMI 1
    VGA 1
    CVBS IN 1
    CVBS OUT 1
    RS232 IN 1
    RS232 OUT 1
    ISP IN 1
    IR IN 1
    CODING BUTTON 1
    AC IN AC100-240V
    Color System Support PAL/NTSC/SECAM
    Control Type IR Remote &Software Control
    Menu Language English/Chinese(Multiple Language can be customized)
    Vertical/Horizontal Display Support
    Combine Display Support combine any horizontal &vertical numbers of screens and show display
      Support combine all screens together to show 1image
    Solid Display Support each screen input with separate signal
    PIP/Zoom/Roaming Support open one window for each screen, each window can be zoomed &roaming internal freely
    Multiple Interfaces Support DVI,HDMI,VGA,AV &multiple signal inputs
    Rich Resolution Support 1080P,1080I,720P,480P &multiple resolution inputs

    Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160

    Slim Bezel Monitor LCD Video Wall Advertising Screens 46" Resolution 3840x2160
